VFD4A8MS21AFSAA

Subscribe to get prices

Model: VFD4A8MS21AFSAA

Order No: DELTA VFD4A8MS21AFSAA

SKU: 10000023461801

Condition: New Sealed Under Guarantee

Size: 16.00 cm,27.00 cm,24.00 cm

Weight: 1.80kg

Product Selection Engineer:ZhangWenBing

In Stock

Brief Introduction

VFD4A8MS21AFSAA

Input Power (V) 230V 1-Phase Output Current (A) 4.80 Control methods IMVF ; IMVFPG ; IMSVC (Space Vector Control) ; IMFOC (Field Oriented Control) Sensorless ; PMSVC Built-in EMC filter Yes Built-in DC reactance No Built-in brake crystal Yes Motor Power (kW) 0.75 Degree of protection IP20/UL Open Type version Wall Mount Safe torque shut-off Yes Motor type Induction Motor(IM) ; Interior Permanent Magnet Motor(IPM) ; Surface Permanent Magnet Motor(SPM) Numeric Inputs (points) 7 Digital Outputs (Points) 2 Relay Outputs (points) 1 Analog Input 0~10V (points) 1 Analog Input: -10~10V (points) 1 Analog Input 0~20mA (points) 1 Analog Input: 4~20mA (points) 1 Analog output 0~10V (points) 1 Analog output -10~10V (points) 0 Analog output: 0~20mA (points) 1 Analog output: 4~20mA (points) 1 Degree of contamination 2 Humidity (%) 90.00 The type of load Constant Torque ; Fan & Pump Application The type of work style Normal Duty ; Heavy Duty Built-in PLC Yes Support external power supply card Yes No. 1 slot card Yes Slot 2 card No No. 3 slot card Not Available Minimum Carrier Frequency (kHz) 2 Maximum Carrier Frequency (kHz) 15 Maximum Output Frequency (Hz) 599.00 Drive type Single Drive Type of inverter module Single Axis Rectifier module type Not Applicable Component type Inverter Module The inverter module is driven into the voltage Not Applicable Built-in motor Not Applicable

Description

Delta VFD4A8MS21AFSAA is a single-phase high-efficiency inverter from the MS series, engineered for light loads in small industrial and commercial equipment with single-phase 200–240V input and 4.8kW rated output power, featuring high reliability and low noise for applications requiring quiet and efficient drive control. It adopts optimized V/F control algorithms ensuring high energy efficiency (>93%) and stable speed regulation (±2% of rated speed), suitable for small centrifugal fans, water circulation pumps, and mini conveyors in commercial buildings, residential facilities, and light manufacturing plants. The inverter has a compact size (100×110×120mm), lightweight design (net weight 1.7kg), and DIN rail mounting, saving space in control cabinets and simplifying installation. It is equipped with basic protection functions including overcurrent, overvoltage, undervoltage, overload (150% for 60s), overheating, and short circuit protection, ensuring safe operation in small drive systems. Low electromagnetic interference (compliant with CE EN55011 Class A) and low noise operation (<54dB) make it suitable for noise-sensitive environments. The user-friendly 3-button keypad allows easy parameter adjustment and fault reset, and the parameter lock function prevents unauthorized changes to settings. With high reliability and low maintenance requirements, it is a cost-effective solution for light loads in commercial and light industrial applications.
