9571-17

Subscribe to get prices

Model: 9571-17

Order No: BENTLY NEVADA 9571-17

SKU: 10000044244901

Condition: New Sealed Under Guarantee

Size: 30.00 cm,30.00 cm,3.00 cm

Weight: 0.50kg

Product Selection Engineer:ZhangWenBing

In Stock

Brief Introduction

9571-17

Bently Nevada cable 9571-17

Description

1、 Model code analysis (9571-XX)
9571: Product Series → 2-core shielded, 22 AWG, non armored, speed sensor specific connecting cable
17 (XX): Cable length → 17 feet (≈ 5.18 meters)
2、 Core technical parameters
1. Electrical and structural
Core specifications: 2-core twisted shielded wire, 22 AWG (0.5mm ²), single core+total shielding, anti electromagnetic interference
Connector configuration: One end is a dual socket plug (compatible with 9200/74712/330500 speed sensors), and the other end is a terminal block (connected to the preamplifier/monitoring module)
Shielding structure: double-layer shielding, stable signal transmission, long distance (≤ 305 meters) attenuation ≤± 3dB
Characteristic impedance: Match Bentley speed sensor standard impedance to ensure signal integrity
Rated voltage: 300V AC/DC
2. Machinery and Environment
Length: 17 feet (5.18 meters)
Outer diameter: approximately 5.0mm
Working temperature: -55 ℃~+121 ℃ (-67 ° F~+250 ° F)
Protection level: IP65, waterproof, dustproof, oil resistant
Bending radius: minimum bending radius ≥ 8 times the outer diameter of the cable
Weight: Approximately 0.6kg/17 feet
3. System adaptation
Compatible sensors: 9200 series speed sensor, 74712 high-temperature speed sensor, 330500 speed sensor
Adaptation system: Bentley 3500/42 monitoring module, 1900/65 vibration monitor, 2300/20 monitor
Transmission distance: Standard 17 feet, maximum up to 305 meters (1000 feet)
Typical application: Transmission of casing vibration/velocity signals for rotating machinery such as steam turbines, compressors, fans, pumps, etc
